| Item | Value |
|---|---|
| Measured gases | CO carbon monoxide |
| Measuring range | 0~1000ppm |
| Detection principle | electrochemical |
| Accuracy | ﹤±5%FS |
| Resolution | 1ppm |
| Response time | 3 seconds |
| Ingress protection | |
| Explosion protection | |
| Operating temperature | -10 ~ 50℃ |
| Power supply | DC 12V~24V |
| Output signal |
|
Operating temperature range |
-10 ~ 50℃ |
|
Operating humidity range |
0 ~ 95%RH |
|
Storage temperature range |
-20 ~ 60℃ |
|
Power input |
DC 12V~24V |
|
Current consumption |
﹤30mA |
|
Signal output |
4~20mA 0-10V or RS-485 |
|
Size: |
220g/114mm×70mm×40mm |
|
Detection method |
electrochemical detection method |
|
Life expectancy |
5 years |
|
Measurement range |
0~1000ppm |
|
Discrimination |
1ppm |
|
Accuracy |
﹤±5%FS |
|
Zero point drift |
<5ppm (within service life) |
|
Response time |
3 seconds |
|
Response time(90%) |
≤ 30 seconds |
There is no Product highlights.
There is no technical parameter expansion description.
It is suitable for industrial safety monitoring and on-site inspection scenarios.
