| Item | Value |
|---|---|
| Measured gases | LNG LNG, COcarbon monoxide, O2oxygen, H2Shydrogen sulfide, LEL flammable gas |
| Measuring range | Flammable and explosive: 0-100%LEL, oxygen: 0-30%vol, CO: 0-999ppm |
| Detection principle | electrochemical |
| Accuracy | <+/-5% full Measuring range |
| Resolution | HD icon drives backlit LCD to display gas level and detector status |
| Response time | |
| Ingress protection | IP65 |
| Explosion protection | North America: ClassI, Div1, GroupsA, B, C, DT4 |
| Operating temperature | -20°C to +50°C (-4°F to +122°F) TempraSURE temperature compensation |
| Power supply | 2xAA alkaline batteries for 14-16 hours, at least 12 hours of operation after each charge, with rechargeable NIMH batteries |
| Output signal | 90 decibels at 30 cm of sound alarm; Visual alarm: Bright red LCD with red backlight |
2-in-1 Gas Detector is easy to use
The Impulse X4 is a portable hazardous gas detector designed to apply advanced principles, reliable, easy to use, inexpensive and without frequent maintenance.
impulse X4 focuses on providing users with practical functional requirements and making it easy for users to use, all of which can be done with the push of a button. In addition, it reduces training requirements compared to the usual multi-gas detectors and can be used in a wide range of industries.
Ease of use does not mean simple functionality, for example, its optional data storage card (the same as the digital camera storage card) can store alarm records, gas data, calibration records, etc., and the operating software can be downloaded from the Zellweger Analytics website, through which graphical curves can be described and printed records can be described.
Ease of use is an important consideration in the design of the impulse X4, and when the detector is worn on a belt or strap, the user may have to remove it in special occasions to observe the display of the screen, which may create a potential hazard for the person or the instrument (e.g. working at height). Impulse X4 users can use the unique "reverse" display function, which can be achieved with just one touch, demonstrating the safety and operability of the design.
The impulse X4 has a very clear LCD display with background light, vibration and audible and visual alarms, which ensures that dangerous gases can be detected in very unfavorable working environments and alert the operator in time.
Rugged and durable housing Reliable to use
Small size and light weight When turned on or needed, it can be used to display displays, batteries, sensors,
Anti-slip, waterproof and integrated design Sound, light, vibration alarm function self-test
Alligator clip or optional strap PatentedSurecellTMSensing andReflexTM
Easy to use Detection technology
・Use directly after taking out ·TempraSURETMTechnology provides temperature compensation
One-button on/off and impact protection
Intuitive prompt characters for multiple languages Periodic flashing/sound cues (user configurable)
User Settings Menu Very good electromagnetic protection performance
Extremely clear background display ・Can be used close to the walkie-talkie
Unique "reverse" display function Exceeds the most demanding electromagnetic protection requirements
Instantaneous, peak, average display High performance-price ratio
Battery, calibration, and self-test status display The two-year shelf life of the whole machine
Effectively gas alarm indication Sensor life of at least two years
Alarm and background light remind attention at the same time Maintenance cost is very low
Outstanding dual-audio sound alarm Can support 1, 2, 3 or 4 types
Gas detection mode with vibration alarm as standard
Impulse X4 PDF document download
Rugged and durable housing Reliable to use
Small size and light weight When turned on or needed, it can be used to display displays, batteries, sensors,
Anti-slip, waterproof and integrated design Sound, light, vibration alarm function self-test
Alligator clip or optional strap clip ·SurecellTMSensing andReflexTM
Easy to use Detection technology
・Use directly after taking out ·TempraSURETMTechnology provides temperature compensation
One-button on/off and impact protection
Intuitive prompt characters for multiple languages Periodic flashing/sound cues (user configurable)
User Settings Menu Very good electromagnetic protection performance
Extremely clear background display ・Can be used close to the walkie-talkie
Unique "reverse" display function Exceeds stringent electromagnetic protection requirements
Instantaneous, peak, average display High performance-price ratio
Battery, calibration, and self-test status display The two-year shelf life of the whole machine
Effectively gas alarm indication Sensor life of at least two years
Alarm and background light remind attention at the same time Maintenance cost is very low
Outstanding dual-audio sound alarm Can support 1, 2, 3 or 4 types
Gas detection mode with vibration alarm as standard
The alarm value increments, alarm value ranges and default alarm values for Minimax X4 series are as follows:
|
|
All alarms |
Level 1 alarm |
Level 2 alarm |
STEL |
TWA |
||||
|
Gas type |
Increments |
Measuring range |
Default |
Measuring range |
Default |
Measuring range |
Default |
Measuring range |
Default |
|
oxygen O2 |
0.1%vol |
21.5～30.%vol |
23%vol |
1.0～20.5%vol |
19%vol |
None |
None |
None |
None |
|
flammable gas Exp |
1%LEL |
2～100 %LEL |
10%LEL |
2～100 %LEL |
20%LEL |
None |
None |
None |
None |
|
carbon monoxide CO |
1ppm |
5～999 ppm |
35ppm |
5～999 ppm |
400ppm |
5～999 ppm |
200ppm |
5～999 ppm |
30ppm |
|
hydrogen sulfide H2S |
1ppm |
3～250 ppm |
10ppm |
3～250 ppm |
40ppm |
3～250 ppm |
10ppm |
3～250 ppm |
5ppm |
The Minimax X4 is a highly portable device that can be used to protect against flammables, oxygen, carbon monoxide and hydrogen sulfide gases. It can be applied both in industry and in protecting personal safety.
