SI-200E O2 Long-Life Fixed Oxygen Detector

P/N: 29033 | Brand: SENKO | Price: On request

SENKO SI-200E O₂ lead-free long-life oxygen detector, >5 years, T90 <15 s, 4–20 mA / RS-485.

Product photo

SI-200E O2 Long-Life Fixed Oxygen Detector
SI-200E O2 Long-Life Fixed Oxygen Detector

Key specifications

ItemSpecification
Target gas & rangeLong-life O₂, 0–30 %Vol class
TypeSI-200E O2 long-life oxygen
Output & alarms4–20 mA, optional relays / RS-485
Protection & ExIP65/66; Ex d or IS as ordered on the plate
Operating temperatureTypically −20 to +55 °C
Certificates / acceptanceSENKO Korea. IECEx/ATEX on the nameplate. A GB scan is not equivalent.

From SENKO published data. Nameplate and current list win.

Description

Galvanic cell. Bias warm-up then stable readings. Non-intrusive magnetic wand.

Key features

  • >5 year life
  • Lead-free O₂
  • T90 <15 s
  • 0.1%Vol
  • HART option
  • Magnetic wand

Key specifications

ItemSpecification
Target gas & rangeLong-life O₂, 0–30 %Vol class
TypeSI-200E O2 long-life oxygen
Output & alarms4–20 mA, optional relays / RS-485
Protection & ExIP65/66; Ex d or IS as ordered on the plate
Operating temperatureTypically −20 to +55 °C
Certificates / acceptanceSENKO Korea. IECEx/ATEX on the nameplate. A GB scan is not equivalent.

From SENKO published data. Nameplate and current list win.

Accessories

  • HART
  • Magnetic wand

Typical applications

Continuous area monitoring in process units, tank farms and pump rooms: 4–20 mA / RS-485 to controllers or DCS, tripping fans and alarms.

Browse by gas

O2

Which model to choose

ModelTarget gasWhen to pick it
SI-200EO₂, toxic or combustible by sensorEx d fixed workhorse, SIL2
SI-200AHCl, NH₃, Cl₂ and O₂/LEL by selectionFaster adsorptive toxics
SI-100CLEL 0–100%, toxics by sensor, O₂ 0–30%VolHeadless budget 4–20 mA point
SI-100DLNG/LPG (methane/propane) 0–100%LELEntry LNG/LPG leak point

FAQ

What does SIL2 mean?
SI-200E is SIL2-assessed and can be used in safety-instrumented loops requiring SIL2.
Sensor life?
EC toxics 2–3 years, lead-free O₂ over 5 years, catalytic 3–5 years; replace the cartridge at end of life.
How is it wired?
4–20 mA (2- or 3-wire by gas) to a controller or DCS; SI-200E adds RS-485 Modbus and three relays.
Mounting height?
Light gases (CH₄, H₂) high; heavy gases (H₂S, LPG) low; O₂/CO at breathing zone — follow GB 50493.
Calibration interval?
Calibrate every 6 months, inspect every 3; the magnetic wand allows one-man calibration without a hot-work permit.
